Model No.

Q×125T-39

Certification

Euro 5+

Engine type

Water cooling 125cc

Engine model

1P52MI

Dispacement

124.8 ml

Cylinder Diameter

52.4 mm

Piston stroke

57.9 mm

Compression ratio

11:1

Max.power(kw/rpm)

8.2KW /7500r/min

Max.torque(N.m/rpm)

10.8Nm /7000r/min

Transimission

Belt drive

Outline size

1977mm×790mm×1376mm

Wheel base

1389 mm

Seater Hight

790 mm

Ground clearence

110 mm

Wet Weight

124kg

Max Loading weight

274 kg

Brake type

F:Disk    /R:Disk

Front tire

130/60-13

Rear tire

130/60-13

Fuel tank capacity

6.8 L

Fuel mode

EFI

Fuel consumption

2.6L/100km

Maxtor speed

85 km/h

Battery

12V7Ah
